PX0410/04S/6570 | PX041004S6570 | Bulgin 400 Series | Connector
400 Series Buccaneer 4 Pole Female Flex Cable Connector
| Complete Electronics Part No | PX041004S6570 |
|---|---|
| Manufacturers Part No. | PX0410/04S/6570 |
| Type | Cable Socket |
| Number of poles | 4 |
| Cable Gland Size | 6.5-7.0 mm |
| Termination | Crimp / Solder |
| Male/Female | Female |
| Rated Voltage | 125V |
| Rated Current | 5A |
| IP Rating | IP68 |
Description
PX041004S6570
400 Series 4 Pole Female Flex Cable Connector
- Voltage: 125Vac/dc
- Current: 5Amps
- Gender: Female
- Application: Cable Mount
- Contacts: Excluded but Crimp/Solder Contacts available separately
- Temperature: -40° to +80°C
- Gland Size: 6.5-7.0mm
- IP Rating: Waterproof & Dustproof to IP68
- Approvals: UL, CSA, VDE & CCC
