PXP7010/32P/CR/0911/SN | PXP701032PCR0911SN | Bulgin 7000 Series
7000 Series Buccaneer Plastic 32 Pole Male Flex Cable Connector
| Complete Electronics Part No | PXP701032PCR0911SN |
|---|---|
| Manufacturers Part No. | PXP7010/32P/CR/0911/SN |
| Type | Cable Plug |
| Mounting | Cable |
| Number of poles | 32 |
| Termination | Crimp |
| Male/Female | Male |
| Housing Construction | Plastic |
| Rated Voltage | 600V |
| Rated Current | 3A |
| IP Rating | IP66 / 68 / 69K |
Description
PXP701032PCR0911SN
7000 Series Buccaneer Plastic 32 Pole Male Flex Cable Connector
- Mates with Flex In-Line or Panel Mount Versions
- Voltage: 600Vac/dc
- Current: 3Amps
- Gender: Male
- Application: Cable Mount
- Contacts: Pins
- Termination: Crimp, excluded, order separately
- Includes Cable Braid Termination
- Temperature: –40° to +120°C
- Gland Size: 9-11mm
- IP Rating: Water and Dust Proof to IP66 / IP68 / IP69
- Approvals: UL, CSA, VDE & CCC
